2. High temperature oxidation treatment of paint, prevent color off and anti-scratch.
3. Strong mechanical making, 5mm thickness metal frame, 20mm thickness aluminium plate flatbed, all mechanical spareparts made from high quality aluminium, insure all parts working stable without distortion and flatbed moving without shake and excursion after longtime working.
4. Grinding treatmented ball screw guide rail go with dual cylindrical rail for Y axis motion. Driver the flatbed motion with high precision.
5. Servo motor with adjustable driver can let the Y axis flatbed moving get precision by 0.01mm. Compare with the step motor, the servo motor can achieve the recycle motion diagnose. It can make the printing very stable and got higher resolution printing. even 5# words can be printed out clearly.
6. Four pieces T type screw guide go with copper nut. make the Z axis motion stable to achieve the printing flatbed surface level on any position.
7. Made in France bearing go with high strength cylcular belt, extend the printer working life and reduce the working noise.
8. High quality PVC waste ink container, easy to be cleaned.
9. Industrial PLC control system is the heart of printer, Before we use the single chip control system, so if any problem will cause the print error, now we use the PLC control system, It is a special alone control center, can dispatch all the working command to different electronic parts separately , and get worked information back. Then process and check itself, also it have self protection problem. Even any problem happen, the PLC will stop for protect the printer and prevent the print head, electronice board and other electronic parts damage. So it is easy to find out the problem and repair it even any problem happend.
--- (Click here to learn more about "PLC" control system)
10. High quality made touch screen control pannel.
11. Automatic up and down limit detecting by industrial red ray sensor. Can prevent the print head and flatbed scratching during printing.
12. Focus newest created ink carriage chips reset system and waste ink pad reset system. Can remove your headache for printer can not recognize chips. Just press a reset button all chips will be reseted.
13. Matching Professional FocusRip white rip and printing software, Get better graphic raster and rapid result while printing with white ink. Powerful function such as clor management, color channel divide management, ICC optional, Whiteness adjustable.
Click here to learn more about FocusRIP
14. Optional solution
A: Solution for sign area when print with eco solvent ink.
B: Solution for dtg area when print with textile ink.
C: Solution for Edible area when print with edible ink. such as cake.
D: Solution for CTS computer direct to screen area for make the digital screen plate when print with CTS ink.
3 Application field:
<1>. Sign making shop
<2>. Photo studio or film development shop
<3>. Screen printing, direct to screen imaging system
<4>. Garment,Textile and fabric, such as the T-shirt, flag, handkerchief, neckerchief...
<5>. Leather, shoes, clothes, crystal and other crafts & gifts industries
<6>. All kind of factories of art items with image
etc...
It is a compliment to screen printing production and heat-transfer industries as it can do some jobs which are very expensive or not possible with the traditional printing.
